Electronic Control Box Subassembly for MRCOOL Wall Mounted Air Handler DIY-36-HP-WMAH-230AE

Name: Electronic Control Box Subassembly for MRCOOL DIY-36-HP-WMAH-230AE
Brand: 36k WMAH Control Board
SKU: 17222000009480
Price: 193.64 USD
Availability: OutOfStock

Brand 36k WMAH Control Board

MRCOOL® PART NUMBER 17222000009480

$193.64

$193.64 ~~$219.96~~

You Save: $26.32

SALE Sold out

✓ Confirmed Fitment

Fits These MRCOOL® Models

DIY-36-HP-WMAH-230AE

This part may fit other MRCOOL® models or generations. Always verify your model number before ordering.

Compatibility matters. Replacement parts are model-specific. Images may be stock photos, and small visual differences may exist between production batches. Verify your model number, serial number, and existing part before placing an order.

Currently Out of Stock

This replacement part is currently unavailable. Contact us for availability or compatibility help.

Not Sure This Is The Correct Part?

Send us your indoor unit model number, serial number, and photos of the existing part before ordering. This helps us verify compatibility and reduce the chance of ordering the wrong replacement part.

Email Fitment Help Call (417) 291-9921

Electronic Control Box Subassembly for MRCOOL Wall Mounted Air Handler DIY-36-HP-WMAH-230AE

Ensure seamless performance and reliability with the Electronic Control Box Subassembly designed specifically for the MRCOOL Wall Mounted Air Handler DIY-36-HP-WMAH-230AE. This high-quality replacement part is engineered to provide precise control over your air handler’s operations, ensuring optimal comfort and energy efficiency in your home. Whether you’re maintaining, repairing, or upgrading your MRCOOL system, this control box subassembly is a vital component to keep your HVAC system running smoothly.

Key Features:

Exact Fit for DIY-36-HP-WMAH-230AE: Designed to integrate perfectly with this MRCOOL model, ensuring hassle-free installation and peak compatibility.
May Fit Other Models: While designed for the MRCOOL DIY-36 series, this control box may also be compatible with other makes and models. Please consult the specifications or contact our support team to verify compatibility.
High-Quality Construction: Manufactured to meet MRCOOL’s rigorous quality standards, ensuring durability and dependable performance in various operating conditions.
Easy Installation: Replace your existing control box with minimal effort, thanks to the user-friendly design.

Specifications:

Part Type: Electronic Control Box Subassembly
Compatible Model: DIY-36-HP-WMAH-230AE (and potentially others)
Functionality: Controls key operations of the wall-mounted air handler, ensuring system reliability and comfort optimization.

Why Choose MRCOOL DIY Direct?

As the USA’s most trusted MRCOOL dealer, MRCOOL DIY Direct offers an extensive range of genuine MRCOOL parts, accessories, and equipment for your residential heating, furnace, and air conditioning needs. We specialize in providing top-notch products that empower homeowners to maintain and repair their HVAC systems with ease.

Authentic Products: We source directly from MRCOOL to ensure you receive genuine, high-quality parts.
Unmatched Support: Our knowledgeable team is always here to help you find the right components and provide guidance on installation.
Fast Shipping Nationwide: Receive your parts quickly and securely with our reliable delivery service.

Additional Notes:

Stock Images: Product images may be representative and not specific to this part.
Customer Support: Not sure if this part fits your system? Contact our support team for expert assistance.

Discover the ultimate convenience of shopping for residential heating, furnace, and air conditioner parts at MRCOOL DIY Direct. Experience the perfect balance of comfort, quality, and savings with our trusted HVAC solutions.

Confirmed Fitment

Known Compatible Models / Series	DIY-36-HP-WMAH-230AE
Compatibility Notice	This part may fit other MRCOOL® models and generations. Compatibility outside the listed models is not guaranteed without verification.

Part Details

Part Category	Indoor Air Handler Electronics
Part Type	Indoor Control Board
Brand	36k WMAH Control Board
MRCOOL® Part Number	17222000009480
Also Known As	Indoor Control Board Indoor PCB Air Handler Control Board Indoor Main Board Circuit Board Electronic Control Module
