MRCOOL 80% AFUE 3 Ton 70,000 BTU Downflow Multi-Speed Gas Furnace, MGD80SE070B3A
Couldn't load pickup availability
Purchasing is unavailable for this option. Contact our team to request an availability notification. Restock timing is not guaranteed.
Shipping options are calculated at checkout.
Verified equipment data
MGD80SE070B3A
Dependable Warmth with the MRCOOL 80% AFUE Downflow Gas Furnace
When winter's chill hits, nothing beats the warmth and security of a reliable gas furnace. Among the top choices available is the MRCOOL single stage, 80% AFUE gas furnace. Specifically designed for downflow installation, this furnace is built to last for decades, delivering powerful heating performance while keeping your energy costs in check. With an 80% AFUE rating, this system ensures that 80% of every dollar spent on heating fuel is converted into effective heat for your home.
Key Features:
- High Efficiency: Achieves 80% AFUE, maximizing your heating budget.
- Downflow Design: Optimized for downflow installation, providing flexibility in various setups.
- Ease of Maintenance: Features an easily removable slide-out blower design for quick and simple upkeep.
- Venting Flexibility: Rotatable draft inducer allows for flexible venting options, accommodating different installation requirements.
- Durable Construction: Aluminized steel tapered crimped non-welded clam shell heat exchanger ensures long-lasting performance.
- Compact Size: Stands at a compact 33" height, fitting easily into tight spaces.
- Flexible Connections: Left or right utility connections offer versatility in installation.
- Efficient Blower Motor: Multi-speed, high-efficiency (constant torque) blower motor delivers consistent, quiet airflow.
- Simple Installation: Zero step horizontal conversion enhances installation simplicity.
- Certified Quality: AHRI Certified, meeting stringent industry standards for efficiency and reliability.
- Warranty: Backed by a registered 10-year parts warranty for added peace of mind.
- LP Kit Available: LP kit not included but available separately for those needing liquid propane conversion.
The MRCOOL 80% AFUE Downflow Gas Furnace is the perfect choice for those seeking reliable, efficient heating that keeps your home warm and your heating bills affordable.
PRODUCT SPECIFICATIONS:
| Product Dimensions | 17 1/2'W x 28 3/8'D x 33'H |
| Product Weight | 128 lbs |
| Unit Type | Gas Furnace |
| AFUE | 80% |
| CFM | 1280 |
| Tonnage | 3 |
| Heating Capacity | 66,000 BTU |
| Fuel Type | Natural Gas |
| BTU Input | 66000 |
| BTU Output |
52800 |
| Voltage |
Requires a minimum of 120V/60HZ/15A |
| Phase | 1 |
| Cycle | 60 |
| Stage | Single |
| Max Fuse Breaker | 15 |
| Min Circuit Ampacity | 6.8 |
| Color | Gray |
| Full Load | 6.8 |
| Number of Burners | 6 |
| Gas Connection Size | 1/2 |
| Blower Motor Type | ECM |
| Blower Motor HP | 1/2 |
| Blower Motor Speeds | 5 Speed |
| Blower Motor RPM | 705-1280 |
| Heat Exchanger Type | Aluminized steel |
| Ignition Type | Silicon Nitride Ignitor |
| Vent Connector | 4 inch |
| LP Kit Available | Yes |
| Certifications | CSA AHRI |
| Warranty |
Registered 10 Year Parts Warranty |
Overview
| Manufacturer warranty | 5 Year Parts Warranty |
|---|
Performance
| Stage | Single |
|---|
Efficiency
| AFUE | 80% |
|---|
Electrical
| Voltage | 120 V |
|---|---|
| Phase | 1 |
| Frequency | 60 Hz |
| Maximum fuse or breaker | 15 A |
| Minimum circuit ampacity | 6.8 A |
Airflow
| Airflow | 1280 CFM |
|---|
Physical
| Depth | 28.38 in |
|---|---|
| Height | 33.00 in |
| Width | 17.50 in |
| Weight | 128.00 lb |
