PRODUCT DESCRIPTION
PRODUCT DESCRIPTION
SPECIFICATION & DIMENSIONS
SPECIFICATION & DIMENSIONS
| Product Dimensions | 33.27 in"W x 14.29"D x 27.64"H |
| Product Weight | 105.16 lbs |
| SEER | 21 |
| EER | 13 |
| HSPF | hspf4/hspf5 : 10.4/9 |
| CFM | 1470.59 |
| Tonnage | 18000 BTU |
| Cooling Capacity | 18000 BTU |
| Heating Capacity | 18000 BTU |
| Voltage | Requires a minimum of 208V-230V/60HZ/15A (please check your home meets this electrical requirement prior to purchase) |
| Phase | 1 |
| Cycle | 60 Hz |
| Max Fuse Breaker | 15 A |
| Min Circuit Ampacity | 12 A |
| Color | White |
| Zone Capacity | 1 |
| Refrigerant Type | R-410A |
| Refrigerant Volume | 68.8 oz |
| Decibel Rating | 58.5 dBA |
| Inverter | Yes |
| Min Ambient Heat | -13 F Degrees |
| Max Lineset Length | 98.42 ft |
| Liquid Line Fitting | 3/8 in |
| Liquid Line Size | 1/4 in |
| Suction Line Fitting | 5/8 in |
| Suction Line Size | 1/2 in |
| Condenser Fan Motor RPM | 850/750/700 |
| Overload Protection | Yes |
| Certifications | UL ETL Energy Star AHRI |
| Registered Warranty | 5-year Parts/7-year Compressor/1-year Remote |
| Proposition 65 Warning | No |
| Restricted States | GU, PR, VI |
