PRODUCT DESCRIPTION
PRODUCT DESCRIPTION
SPECIFICATION & DIMENSIONS
SPECIFICATION & DIMENSIONS
| Product Dimensions | 39 3/8"W x 14 1/2"D x 53 3/4"H |
| Product Weight | 308.7 lbs |
| SEER | up to 18 |
| Max SEER | 18 |
| EER | 10.5 |
| HSPF | 10 |
| CFM | 4700 |
| Tonnage | 4-5 Ton |
| Cooling Capacity | 54,000 BTU |
| Heating Capacity | 54,000 BTU |
| Electrical Requirements | Requires a minimum of 208V-230V/60HZ/35A-45A (please check your home meets this electrical requirement prior to purchase) |
| Phase | 1 |
| Cycle | 60 Hz |
| Max Fuse Breaker | 35 A |
| Min Circuit Ampacity | 24 A |
| Color | Gray |
| Refrigerant Type | R-410A |
| Refrigerant Volume | 220.48 oz |
| Decibel Rating | 58 dBA |
| Inverter | DC |
| Min Ambient Cool | 5F - 129.2F |
| Min Ambient Heat | -22F - 75.2F |
| Lineset Included | No |
| Line Set Length | 15ft, 25ft, 35ft, 50ft |
| Max Lineset Length | 164 FT / 5 |
| Lineset Fitting Type | Pre-Flared/Sweat & Quick Connect |
| Liquid Line Size | 3/8 in. |
| Suction Line Size | 3/4 in. |
| Compressor Motor Type | Inverter Rotary |
| Condenser Fan Motor Type | Direct Drive |
| Metering Device | EEV |
| Auxiliary Heater Available | Yes |
| Certifications | ETL Energy Star AHRI |
| Warranty | 10 Year Registered Limited Warranty 5 Years Parts |
| Restricted States | No |
