PRODUCT DESCRIPTION
PRODUCT DESCRIPTION
SPECIFICATION & DIMENSIONS
SPECIFICATION & DIMENSIONS
Category | Specification |
---|---|
Cooling Capacity (Btu/h) | 24,000 |
SEER2 | 18.1 |
EER2 | 11.0 |
Heating Capacity (Btu/h) | 26,000 |
HSPF2-4 | 9.7 |
HSPF2-5 | 7.7 |
Indoor Noise Level (Turbo/Hi/Mi/Lo) | 44 / 42 / 28 dB(A) |
Outdoor Noise Level | 60 dB(A) |
Power Supply (Indoor) | 115/208/230V ~ 60Hz, 1ph |
Power Supply (Outdoor) | 208/230V ~ 60Hz, 1ph |
Min Circuit Ampacity (Indoor) | 5.5 / 4.0 A |
Max Fuse (Indoor) | 15 A |
Min Circuit Ampacity (Outdoor) | 19 A |
Max Fuse (Outdoor) | 20 A |
Indoor Unit Dimensions (WxDxH) | 17.52 x 21.02 x 45.00 in |
Indoor Packing Dimensions (WxDxH) | 20.87 x 26.57 x 48.62 in |
Indoor Net/Gross Weight | 105.60 / 127.43 lbs |
Outdoor Unit Dimensions (WxDxH) | 35.04 x 13.46 x 26.50 in |
Outdoor Packing Dimensions (WxDxH) | 39.17 x 15.67 x 29.13 in |
Outdoor Net/Gross Weight | 102 / 109 lbs |
Indoor Airflow (CFM Turbo/Hi/Mi/Lo) | 824 / 759 / 695 / 630 |
Outdoor Airflow (CFM) | 1765.7 |
Refrigerant Type | R-454B |
Refrigerant Charge | 74.08 oz |
Piping Size (Liquid/Gas) | 3/8" - 3/4" |
